Measured Building Survey London | Laser-Accurate

Why does a planning or building regulations application need a measured survey?

A planning or building regulations application needs to show the existing building accurately alongside the proposed changes, so the council or Building Control can judge the impact of the work against what is actually there. Existing plans, elevations and sections drawn from an accurate measured survey give the borough confidence that the proposal has been designed against real dimensions, and give your builder a reliable set of drawings to price and build from — an application based on inaccurate or assumed dimensions risks queries, delays, or a design that does not translate cleanly on site.

What does a measured building survey capture?

The survey records everything needed to produce accurate existing drawings: internal room dimensions and floor-to-ceiling heights on every level, the position, width and height of every door and window, wall thicknesses, staircase dimensions and headroom, roof shape and pitch, chimney breasts and structural features, and the external footprint and boundary relationship of the property. Where relevant to the project, we also record ground levels, existing drainage runs and neighbouring boundary conditions.

This is captured with a laser distance meter rather than a tape measure, which keeps the survey accurate to within a few millimetres across a whole property and removes the cumulative measuring error that can creep into a hand-measured survey of a larger or more complex building.

Can I reuse an old survey or estate agent floor plan instead?

Generally, no — estate agent floor plans are produced for marketing purposes and are not dimensionally accurate enough to design an extension or loft conversion against, and a previous owner's drawings may not reflect alterations made since, or may simply be inaccurate to begin with. A fresh measured survey is a modest cost relative to the overall project and is the single best way to avoid a redesign once a builder is on site and finds the real dimensions differ from the drawings.

How much does a measured building survey cost in London?

A measured building survey starts from £450 as a standalone instruction, or is included as the first step within a planning, building regulations or architectural drawing package. The exact fee depends on the size of the property, the number of floors, and the complexity of the roof and internal layout. Because the survey underpins everything that follows — floor plans, planning drawings, building regulations drawings and any structural calculations — it is typically instructed once at the very start of a project rather than repeated.

Do I need a new survey if I already have plans from a previous project?

It depends on how old the plans are and whether the property has changed since. If the plans are recent, accurate and reflect the current layout, they can sometimes be reused as the base for a new design, saving the cost of a repeat survey. If they predate a previous alteration, are hand-drawn or estimated rather than laser-measured, or you are unsure of their accuracy, a fresh survey is the safer and usually more cost-effective option — it removes any risk of designing on top of inaccurate existing information.
